White 414 - Page 15

15
Model 414
REF.
NO.
PART
NO DESCRIPTION
1 735-0246 Vinyl End Plug
2 647-0014 Clutch Control Ass’y.
3 710-1017 Torx Mach. AB-Tap Scr. 1/4 x .62"
4 786-0131 Handle Cover
5 786-0098 Retaining Brkt.—R.H.
6 786-0118 Retaining Brkt.—L.H.
7 720-0278 Grip (2 Req’d.)
8 720-0210A Knob
9 712-3008 Hex Jam Nut 3/8-16 Thd.
11 735-0127 Rubber Washer
12 736-0204 Fl-Wash. .344" I.D. x .6" O.D.
13 747-0902 Gear Shift Rod
14 714-0104 Hairpin Clip
15 649-0017 Handle Ass’y.
16 710-0896 Tap Scr. 1/4-14 x 5/8" Lg.
17 726-0330 Cable Clip
21 746-0916 Clutch Cable
22 786-0120 Depth Bar
23 736-0117 Fl-Wash. 3/8" I.D. x 5/8" O.D.
24 710-0253 Hex Bolt 3/8-16 x 1" Lg.*
28 715-0120 Spiral Pin 3/16" x 1"
29 686-0095 Shift Crank Ass’y.
30 711-0415 Clevis Pin
31 714-0149B Hairpin Clip
32 642-0015 Tine Ass’y.—L.H.
642-0016 Tine Ass’y.—R.H. (Not Shown)
33 786-0090 Side Shield
34 786-0113 Rear Tine Shield
35 686-0044A End Cover Ass’y.
36 738-0849 Hex Cap Bolt 5/16-18 x 1.25" Lg.
38 710-0376 Hex Bolt 5/16-18 x .75" Lg.
39 710-3097 Carriage Bolt 3/8-16 x 1" Lg.
40 712-0798 Hex Ins. L-Nut 3/8-16 Thd.
43 712-3004A Hex Flange Top L-Nut 5/16-18
44 786-0076 Tine Shield Brkt.—R.H.
45 786-0077 Tine Shield Brkt.—L.H.
46 711-0415 Clevis Pin .375" Dia.
47 786-0085 Tine Shield
48 747-0432 Tiller Flap Rod
49 726-0106 Cap Speed Nut
50 710-0189 Hex Bolt 5/16-18 x 3" Lg.
51 786-0101B Shift Cover (410, 412 & 422)
786-0168 Shift Cover (415 & 417)
52 710-1017 Torx Mach. AB-Tap Scr. 1/4 x .6"
54 786-0109 Handle Brkt.—L.H.
55 786-0108 Handle Brkt.—R.H.
56 784-0191 Hex Nut Retainer Brkt.
57 712-0379 Hex Flange Nut 3/8-24 Thd.
58 750-0885 Spacer .322 Dia.
59 784-0190 Handle Adjustment Crank
60 712-0421 Knob 5/16-18 Thd.
61 736-0169 L-Washer 3/8" I.D.
REF.
NO.
PART
NO DESCRIPTION
PART
NO DESCRIPTION
777D01165 WOP Handle Panel
777D01168 WOP Belt Guard
777D02432 WOP Engine
777S30038 Rear Tine Warning
777-4102 R N F T
777I20358 Place Hand Here
777I20362 Operating Instructions
777I20363 Shift Cover
777I20364 FNR Front Handle
LABELS
NOTE: For painted parts, please refer to
the list of color codes below. Please add the
applicable color code, wherever needed, to
the part number to order a replacement part.
For instance, if a part, numbered 700-xxxx,
is painted Oyster Gray, the part number to
order would be 700-xxxx-0662.
Oyster Gray: 0662
Powder Black: 0637
