White 414 - Page 16

16
Model 414
REF.
NO. PART NO. DESCRIPTION
1 710-3008 Hex Bolt 5/16-18 x .75" Lg.
2 712-3004A Hex Top L-Nut 5/16-18 Thd.
3 786-0107 Cable Mtg. Bracket
4 710-1017 Torx Mach. AB-Tap Scr. 1/4 x .6" Lg
5 738-0899 Belt Cover Bolt
6 786-0117 Shift Cover Bracket
7 786-0100 Belt Cover
8 736-0142 Fl-Wash. .281" I.D. x .5" O.D.
9 712-0392 Hex Cap Nut 1/4-28 Thd.
10 756-0634 Flat Pulley 8" O.D.
11 736-0105 Bell-Wash. .38" I.D. x .88" O.D.
12 712-0379 Hex Flange Nut.
13 754-0438 “V”-Belt
14 686-0031 Belt Keeper Brkt.
15 736-0119 L-Wash. 5/16" I.D.
16 710-0237 Hex Bolt 5/16-24 x .62" Lg.
17 738-0876 Shld. Nut
18 712-0266 Hex Jam L-Nut 3/8-16 Thd.
19 756-0405 Fl-Idler w/Flanges
20 710-0152 Hex Bolt 3/8-24 x 1" Lg.
21 736-0217 L-Wash. 3/8" I.D.
22 736-0258 Fl-Wash. 3/8" I.D. x 1" O.D.
23 756-0972 Outer Engine Pulley Half
24 756-0971 Inner Engine Pulley Half
25 786-0080 Idler Bracket
26 710-0723 Hex Bolt 3/8-16 x 1.25" Lg.
27 746-0916 Clutch Cable
28 734-0255 Air Valve
29 714-0104 Hairpin Clip
30 711-1017 Clevis Pin
31 634-0112 Rim Only (14")
634-0108 Rim Only (16")
32 634-0110 Wheel Ass’y. Comp.—R.H. (14")
634-0111 Wheel Ass’y. Comp.—L.H. (14")
634-0106 Wheel Ass’y. Comp.—R.H. (16")
634-0107 Wheel Ass’y. Comp.—L.H. (16")
734-1796 Tire Only (14")
734-0808 Tire Only (16")
34 619-0009 Frame Counterweight
35 710-1007 Hex TT-Tap Scr. 3/8-16 Thd.
36 710-0376 Hex Bolt 5/16-18 x 1" Lg. (Gr. 5)
37 712-3004A Hex Flange L-Nut 5/16-18 Thd.
38 — Engine
41 686-0043A Tine Shield Brkt. Ass’y.
42 710-3038 Hex Bolt 5/16-18 x 7/8" Lg.
43 736-0256 Wash. Fl..635 I.D. x .930 O.D. x .03
REF.
NO. PART NO. DESCRIPTION
