WHITE can accept no responsibility for possible errors in catalogues, brochures, and other printed material. WHITE reserves the right to alter its products without noce. This also applies to products already on
order provided that such alteraons can be made without subsequent changes being necessary in specicaons already agreed.
All trademarks in this material are the property of the respecve companies. WHITE and the WHITE logotype are trademarks of WHITE Drive Motors & Steering LLC and WHITE Drive Motors and Steering Sp. z o.o..
All rights reserved.
Place the gearwheel set on the cardan sha so that the top of a
tooth in the external teeth of the gearwheel is vercally above
the mark on the cardan sha.
Turn the gearwheel set counter clockwise unl the cardan sha
and the gearwheel start to mesh (15°). Turn the gearwheel rim so
that the holes made for the screws line up.
12
End cover
Turn the end cover so that the holes line up
16, 17
Washer, screws
Use a 13 mm spanner socket Tightening torque: 30 - 35 N•m
[265-310 lbf•in]
14, 15
Washer, drain plug
Use a 17 mm spanner socket. Tightening torque: 32 - 44 N•m
[283-389 lbf•in]
3
Seal plugs Threaded
plug (if present)
Screw in plasc plugs
7
Woodru key
To be secured with tape or plasc ring
Table 5: Assembling DH / DS
