DH spare part list
Item
Spare parts
Dimensions
Code No
Number per motor
1
Dust seal ring
28.56 × 35.00 × 2.20
633B0370
1
[1.25 × 1.38 × 0.09]
2
Housing and output sha
-
-
3
Plug (plasc)
7/8-14 UNF
633X0017
2
1/2 - 14 NPTF
11042922
2
Manifold
11043191
2
4
Sha seal
28.56 × 39.00 × 4.57
633B0361
1
[1.25 × 1.54 × 0.18]
5
Bearing race
11043824
1
6
Axial needle bearing
11043825
1
7
Woodru key
1/4 × 7/16 × 1
682L9054
1
8
Cardan sha
DH 36
L = 76.8 mm [3.02 in]
11041237
1
DH 50
L = 76.8 mm [3.02 in]
11041237
1
DH 80
L = 80.7 mm [3.18 in]
11041239
1
DH 100
L = 83.3 mm [3.28 in]
11041238
1
DH 125
L = 87.1 mm [3.42 in]
11041240
1
DH 160
L = 91.2 mm [3.59 in]
11041242
1
DH 200
L = 96.4 mm [3.80 in]
11041244
1
DH 250
L = 102.9 mm [4.05 in]
11041247
1
DH 315
L = 111.4 mm [4.39 in]
11041246
1
DH 400
L = 122.6 mm [4.83 in]
11041243
1
9
O-ring
75.9 × 1.8 mm
633B1173
3
10
Distributor plate
151-1713
1
11
Gearwheel set
DH 36
w = 5.9 mm [0.23 in]
151-1258
1
DH 50
w = 6.5 mm [0.26 in]
151-1126
1
DH 80
w = 10.4 mm [0.41 in]
151-1127
1
DH 100
W = 13.0 mm [0.51 in]
151-1128
1
DH 125
w = 16.3 mm [0.64 in]
151-1112
1
DH 160
w = 20.8 mm [0.82 in]
151-1129
1
DH 200
w = 26.0 mm [1.02 in]
151-1185
1
DH 250
w = 32.5 mm [1.28 in]
151-1193
1
DH 315
w = 40.9 mm [1.61 in]
151-1186
1
