Chapter 5
Assembling
DH/DS assembling
Place the motor housing in the holding tool with the ange
upwards
Lubricate the sha seal on the outside with hydraulic oil. Fit the
sha seal correctly onto mandrel SJ 151-0414 and carefully press
the sha seal into posion in the motor housing
Place the dust seal ring in the spigot ange and knock it into
posion with a plasc hammer and appropriate mandrel. SJ 151-
9000-7 or SJ 151F9000-7
Fit bearing and bearing race onto the sha and mount together
with the sha
Grease the journals with hydraulic oil. The rear sha end must be
marked before ed. The mark must be posioned vercally
above a commutaon slot leading up to the front annular channel
Grease the O-ring and put it in the O-ring groove of the housing
Turn the distributor plate so that the holes line up
Guide the cardan sha down into the motor housing.
Only DH 36 and 50. Place the assembly tool under the upper
splines of the cardan sha.
In case of dierent splines lengths turn the cardan sha to ensure
the long splines end is ed in the output sha.
Transfer marking from output sha to cardan sha.
Place the O-rings (greased) in the O-ring grooves of the
gearwheel.
In gearwheels with non through splines place the gearwheel with
the recess in the spline hole facing down towards the housing.
