2015 Edition 1 Page 8
WHYTE Service Manual
Frame Size
Small Medium Large
Head Angle 66.5° 66.5° 66.5°
Seat Angle 73.0° 73.0° 73.0°
Top Tube 598.7mm 617.5mm 635.1mm
BB Height* 305.0mm 305.0mm 305.0mm
Stand Over 777mm 805mm 832mm
Wheel Base 1118.8mm 1138.8mm 1168.8mm
Chain Stay 425mm 425mm 425mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra Large
66.5°
73.0°
653.9mm
305.0mm
861mm
1188.8mm
430mm
30.9mm
2.2.6: WHYTE 901 & 905
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 54-584)
Frame Size X
Small Medium
Head Angle
A
68.5° 68.5°
Seat Angle
B
73.5° 73.5°
Top Tube
C
585.5mm 599.6m
BB Height*
D
303.5mm 303.5mm
Stand Over
E
784mm 804mm
Wheel Base
F
1099.1mm 1114.1mm
Chain Stay
G
435mm 435mm
Seat Post
H
30.9mm 30.9mm
2.2.5: WHYTE 604, 802 & 806
Note:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 52-584).
