Frame Size
Small Medium Large
Head Angle 66.2° to 66.8° 66.2° to 66.8° 66.2° to 66.8°
Seat Angle 72.7° to 73.3° 72.7° to 73.3° 72.7° to 73.3°
Top Tube 598.7mm 617.5mm 635.1mm
BB Height* 305mm 305mm 305mm
Stand Over
782mm to
788mm
788mm to
804mm
827mm to
833mm
Wheel Base
1108.7mm to
1128.7mm
1128.7mm to
1148.7mm
1148.7mm to
1168.7mm
Chain Stay
415.0mm to
435mm
415.0mm to
435mm
415.0mm to
435mm
Seat Post 30.9mm 30.9mm 30.9mm
X
A
B
C
D
E
F
G
H
Extra - Large
66.2° to 66.8°
72.7° to 73.3°
653.9mm
305mm
857mm to
863mm
1173.8mm to
1193.8mm
420.0mm to
440mm
30.9mm
2.2.7: WHYTE 909
Notes:
Geometry shown here is ’Showroom’ i.e. without rider aboard the bicycle. ’With Sag’ geometry is with rider after correct
sag is set at the front. Please refer to suspension set up for information on how to achieve the correct sag of the fork.
* BB height with Ø717mm tyres fitted (2.25” / 52-584).
Whyte 929 has an adjustable rear drop-out, see section 3.4. When fully extended rearwards, this adds 10mm to Chain
-stay and Wheelbase lengths. When fully retracted forwards, the reduces Chain-stay and Wheelbase lengths by 10mm.
