WICKEDedge WE120 - Step 7: Slide L-bracket Assemblies

Step 7: Slide L-bracket, Ball Joint and
Guide Rod Assembly onto each end
of the Degree Bar as shown in Figure
15. The Ball Joints should be facing
inward toward the Vise.
Fig. 15
wickededgeusa.com • assembly guide • 23
