WIKA Operating instructions / Betriebsanleitung / Mode d'emploi PS-20, PS-21








 Schliesser / make contact / fermant Typ 1 / Type 1
oberer Schaltpunkt (P2) schaltet in "high", unterer Schaltpunkt (P1) in
"low"/
upper sp (P2) switches into "high" lower sp (P1) switches into "low"/
le point de commutation haut (P2) commute en "high", le point de
commutation bas (P1) commute en "low"
 Öffner / break contact / ouvrant Typ 0 / Type 0
oberer Schaltpunkt (P2) schaltet in "low", unterer Schaltpunkt (P1) in
"high"/
upper sp (P2) switches into "low" lower sp (P1) switches into "high"/
le point de commutation haut (P2) commute en "low", le point de
commutation bas (P1) commute en "high"
Configuration software Easy Switch
P1
P2
high
low
p/bar
P1
P2
high
low
p/bar
FGBD
