6
SLIDETRAX
TM
ACCESSORY SYSTEM
One of the most appealing and useful features
on the Commander is the dual SlideTrax System—
a modular, movable accessory outfitting system.
One set of SlideTrax rails is positioned on top of
the deck in front and a second set runs along the
side of hull from bow to stern on each side.
Accessories can be installed, removed, or
repositioned as desired. They attach to the
SlideTrax via a screw and rectangular plate
captured within the track.
Each Commander comes standard with dual
adjustable bow and stern bungee cord systems.
The bungee cord is routed through unique SlideTrax
Fittings that have holes to allow line to be pushed
through for maximum security and are “hooked” as
well so that they capture line that is looped under
them. Each fitting is also removable or can be
repositioned as desired by loosening the socket
head screw with a 3/16” hex wrench.
On the stern bungee system the cord is looped
under the center fitting on each side rather than
through the eyelet on the fitting. This allows you to
open up the tankwell completely by simply
unhooking the bungee from the center fittings and
letting it fall open, providing complete access to
tankwell.
INSTALLATION OF ACCESSORIES ON
TOP-MOUNTED SLIDETRAX RAILS:
1. Remove base plates from screws on
accessory and slide plates into desired
track from forward end of track.
2. Align screws over base plates and start
each mounting screw into threaded hole
in base plate.
3. Slide accessory to desired position and
tighten securely.
To see the complete line of SlideTrax
accessories, visit www.HarmonyGear.com
INSTALLATION OF ACCESSORIES
ON SIDE SLIDETRAX RAILS:
1. Use a Phillips screwdriver to remove screw
holding the rail end cap at bow of boat to
insert base plates for bow-positioned
accessories. At stern end, it will be necessary
to reach inside of boat to hold rubber wellnut
while removing screw. Retain hardware for
reinstallation of end cap.
2. Remove base plates from screws on accessory
and slide plates into rail. It may be necessary,
depending on accessory and desired position,
to loosen or move existing fittings on the rail.
You may fin d it more conve nient to unscrew the
bungee fittings from the SlideTrax rail and move
the brass plate forward or back to position
desired for new accessory and then slide new
brass plate into position for bungee fittings.
3. Align screws over base plates and start each
mounting screw into threaded hole in base
plate.
4. Tighten securely when desired position for
accessory is determined.
5. Replace end cap on end of rail with original
hardware.
