PERSONAL PA SYSTEM 400 SPECIFICATIONS
PERSONAL PA Transmitter Model T17/*
Dimensions & Weight: 3.25" W x 6.875" L x 1.75" H (82.5mm x
174.6mm x 44.5mm); 13 oz., 368.5 g
Color: Black
Power (U.S./Canada): 105-130 VAC, 50-60Hz, .5W
Operating Frequencies: CH 13 (72.100 MHz), CH 18 (72.300MHz),
CH 23 (72.500MHz), CH 28 (72.700MHz),
CH 33 (72.900MHz), CH 38 (74.700MHz)
CH 43 (75.300 MHz), CH 48 (75.500MHz),
CH 53 (75.700MHz), CH 58 (75.900MHz),
CH 33 (72.900MHz) is standard
Frequency Selector: Internal switches, 10 channels
RF Field Strength: 8000 µV/m at 30 m Max., 20mW typical
Nominal Range: 300–500 feet, 90–150m
Modulation: 5 kHz (narrow–band)
Stability: ± .005% over 0-50˚C
FCC ID: CNMT17
Pre-Emphasis:
Frequency Response:
Distortion:
Signal to Noise Ratio:
Microphone Input:
Mic Input Level:
Line-Level Input:
Line Input Level:
Input Attenuator:
Antenna Outputs:
300 µS
100 Hz - 5 kHz ±3dB
1 % Max. THD
50–55 dB with R19 Receiver
3.5mm mini phone jack, supplies +DC
for electret mics
1 - 10 mV, nominal
RCA Jack, Hi Z, unbal.
.1 - 1 Vrms, nominal
Pot, screwdriver-adjust
Thread Mount for "rubber duckie" flexible
whip antenna, optional hard-wired 75½
Coaxial Antenna (ANT 005) uses RG-59
cable, 400ft. (140m) max. cable length
*NOTE: The T17 Transmitter is field-tunable to any of 10 narrow-band channels. Specific transmitter model names
contain a frequency code. For example, Model T17/33 is preset to channel 33.
PERSONAL PA Receivers: Model R19/*, Model R19-4A, Model R19-6
Model PPA R19: 2-Channel, Pre-Tuned, Selectable
CH 33 (72.9 MHz), CH 53 (75.7 MHz)
standard
10 Channels Available (72.1-75.9 MHz)
Model PPA R19–4: 4-Channel, Pre-Tuned, Selectable
CH 13 (72.1 MHz), CH 23 (72.5 MHz),
CH 33 (72.9 MHz), CH 53 (75.7 MHz)
Model PPA R19–6: 6-Channel, Pre-Tuned, Selectable
CH 13 (72.1 MHz), CH 23 (72.5 MHz),
CH 33 (72.9 MHz), CH 53 (75.7 MHz)
CH 38 (74.7 MHz), CH 43 (75.3 MHz)
Dimensions: 3-5/8" L x 2-3/8" W x 7/8" H
(92.1 mm x 60.3 mm x 22.2 mm)
Weight: 3.2 oz (90 g) with battery
Color: Neptune Blue
Battery Type: (2) BAT 001 AA Alkaline
or (2) BAT 026 Ni-Cad
Battery Drain: 20 mA, nominal
Battery Life: 90–100 hrs with 2 AA Alkaline
45-50 hrs/charge with BAT 026
Operating Freq:
Crystal controlled. See factory for
frequency changing instructions.
Intermediate Freqs: 10.7 MHz, 455 kHz
FCC ID:
Earphone:
Output Connector:
FM Deviation:
De-Emphasis:
Sensitivity:
Squelch Level:
Frequency Response:
Receiver Antenna:
Signal-to-Noise Ratio:
Audio Output:
Acoustic Output:
CONTROLS
Tone:
Volume & On/Off:
Channel Selector:
CNMR19
Earbud-type with foam cushion,
3.5 mm plug, 32
½
3.5 mm mono mini phone jack
Narrow–band, 5 kHz
300 µS
0.7 µV at 12 dB Sinad
4 µV for minimum 40 dB S/N ratio
100 – 5 kHz, ± 3 dB (Tone: Lo)
Integral with earphone cord
50dB
35 mW, max. at 16
½
(Tone: Lo; 3 VDC Bat.)
125 dB Max SSPL90 with EAR 013
Switched Low-Cut
Lo: 20 Hz / Mid: 120 Hz / Hi: 700 Hz
Combination, integral
PPA
R19: 2-position, slide switch
PPA R19-4: 4-position, rotary switch
PPA R19-6: 6-position, rotary switch
*NOTE: Specific receiver model numbers contain a frequency code. For example, Model R19/33/53 is preset to
channels 33 and 53. The R19 and R19-4 Receivers are crystal-controlled for optimal stability. If the standard
R19 or R19-4 channels cannot be used, the receiver must be returned to the factory for alternate crystals.
