22
CLEAN THE DETERGENT DISPENSER
1. Press down the arrow location on softener cover inside the
dispenser drawer.
2. Lift the clip up and take out softener cover and wash all grooves
with water.
3. Restore the softener cover and push the drawer into position.
NOTE!
Do not use alcohol, solvents or chemical products to clean the
machine.
CLEANING THE DRAIN PUMP FILTER
WARNING!
• Be careful of the hot water!
• Allow detergent solution to cool down.
• Unplug the machine to avoid electrical shock before washing.
• Drain pump lter can lter the yarns and small foreign matters
from the washing.
• Clean the lter periodically to ensure the normal operation of
washing machine.
CLEANING THE DRAIN PUMP FILTER (CONT.)
CAUTION!
• Make sure that valve cap is reinstalled properly, cap plates
should be inserted aligning to hole plates otherwise water may
leak;
• Rotate lower cover cap directly to make water run
into basin.
• When the appliance is in use and depending on the program
selected there can be hot water in the pump. Never remove
the pump cover during a wash cycle, always wait until the
appliance has nished the cycle, and is empty. When replacing
the cover, ensure it is securely re-tightened.
1) Pull out the dispenser
drawer with press the A
1) Open the lower
cover cap
2) Clean the dispenser
drawer under water
2) Rotate 90°C and take
o the hose cap
3) Clean inside the recess
with an old toothbrush
3) After water runs out,
reset the drain hose
5) Remove foreign objects
4) Reinsert the
dispenser drawer
4) Open the lter
by turning it
counter clockwise
6) Close the lower
cover cap
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.
Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1
2
3
4
Note!
Note!
Note!
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
22
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.
Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1
2
3
4
Note!
Note!
Note!
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
22
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.
Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1
2
3
4
Note!
Note!
Note!
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
22
Washing the filter in the tap
1.Close the tap.
2.Remove the water supply hose from the tap.
3.clean the filter.
4.Reconnect the .water supply hose
Cleaning The Inlet Filter
• Inlet filter must be cleaned if there is less water.
• If the brush is not clean, you can pull out the filter washed separately;
• Reconnect, turn on the tap.
Washing the filter in washing machine:
1.
Screw off the inlet pipe from the backside
of the machine.
2.Pull out the filter with long nose pliers
and reinstall it back after being washed.
3.Use to clean the filter.
4.Reconnect the inlet pipe.
the brush
Clean The Detergent Dispenser
Do not use alcohol,solvents or chemical products to clean the machine.•
A
Pull out the dispenser
drawer with press the A
Clean the dispenser
drawer under water
Clean inside the recess
with an old toothbrush
Insert the dispenser
drawer
1
2
3
4
Note!
Note!
Note!
1.Press down the arrow location on softener cover inside the dispenser drawer.
2.Lift the clip up and take out softener cover and wash all grooves with water.
3.Restore the softener cover and push the drawer into position.
MAINTENANCES
22
• Make sure that valve cap and emergency drain hose are reinstalled properly, cap
plates should be inserted aligning to hole plates otherwise water may leak.
• Some machines don’t have emergency drain hose, so step 2 and step 3 can be skipped.
Rotate lower cover cap directly to make water run into basin.
• When the appliance is in use and depending on the programme selected there can
be hot water in the pump. Never remove the pump cover during a wash cycle, always
wait until the appli
ance has finished the cycle, and is empty. When replacing the
cover, ensure it is securely re-tightened.
Cleaning The Drain Pump Filter
Be careful of the hot water!
Allow detergent solution to cool down.
•
•
• Unplug the machine to avoid electrical shock before washing.
• Drain pump filter can filter the yarns and small foreign matters from the
washing.
• Clean the filter periodically to ensure the normal operation of washing
machine.
Open the lower cover cap
Rotate 90°C and pull out
the emergency drain hose,
and take off the hose cap
Open the filter by turning
to the counter clockwise
Remove extraneous matter
1
2
3
Close the lower cover cap
6
5
4
Emergency
drain hose
After water runs out,reset
the drain hose
Warning!
！！
Caution!
MAINTENANCES
23
• Make sure that valve cap and emergency drain hose are reinstalled properly, cap
plates should be inserted aligning to hole plates otherwise water may leak.
• Some machines don’t have emergency drain hose, so step 2 and step 3 can be skipped.
Rotate lower cover cap directly to make water run into basin.
• When the appliance is in use and depending on the programme selected there can
be hot water in the pump. Never remove the pump cover during a wash cycle, always
wait until the appli
ance has finished the cycle, and is empty. When replacing the
cover, ensure it is securely re-tightened.
Cleaning The Drain Pump Filter
Be careful of the hot water!
Allow detergent solution to cool down.
•
•
• Unplug the machine to avoid electrical shock before washing.
• Drain pump filter can filter the yarns and small foreign matters from the
washing.
• Clean the filter periodically to ensure the normal operation of washing
machine.
Open the lower cover cap
Rotate 90°C and pull out
the emergency drain hose,
and take off the hose cap
Open the filter by turning
to the counter clockwise
Remove extraneous matter
1
2
3
Close the lower cover cap
6
5
4
Emergency
drain hose
After water runs out,reset
the drain hose
Warning!
！！
Caution!
MAINTENANCES
23
CLEANING & MAINTENANCE (CONTINUED)
