WILMS BV 385 - Pre-Set Values

WILMS BV - SERIES Issue: 14.10.1999
Pre-set values
Type BV 385
Burner GG175-WLE
Width of turbulator 42 mm
Date 14.10.99
Adjustment specifications
Nozzle Danfoss
Spray character fully
Nozzle size USgal/h 2,25
Spray angle ° 60
Nozzle type EN
Pump pressure bar 12,5
Fuel throughput kg/h 9,185
Delivered capacity kW 108,43
Exhausts
CO² % -
O² % 2,9
CO² from O² % 13,2
CO ppm 0
NOx ppm 87,0
CO mg/kWh
NOx mg/kWh
Soot Ba 0,1
Temperature
Exhaust °C 220,1
Ambient °C 23,7
Combustion chamber °C -
Various informations
Pressure baffle plate hPa 4,3
Press. combust. chamber hPa 0,78
Pressure exhaust hPa 0,12
Loss through exhaust % 8,82
Efficiency % 91,18
Measurement A mm 14,0
Measurement B mm 15,9
Measurement C mm 35
Nozzle-baffle plate 8 mm
These dates are from the test set-up. Different conditions for the heaters can result in
variations of these values.
