Spare Parts List
Burner BV 385
Pos. Order-No. D E S C R I P T I O N Qty.
01 6163970 Burner Pipe 01
02 6163971 Baffle Plate with Holder and Twin Electrode 01
03 6163999 Twin Electrode 01
04 6163974 Nozzle Plate complete 01
05 6163975 Ignition Cable 700 mm 02
06 6163976 Sliding Flange, straight 01
07 6163977 Burner Flange Gasket 01
08 6163978 Air Flap Burner 01
09 6163979 Housing without Suction Absorber 01
12 6163980 Pressure Pipe Pump - Nozzle Plate 01
14 6163981 Fan Wheel 01
16 6162710 Suntec Pump AS 47 D 01
17 6162751 Fuel Hose - 750 mm 02
18 6162644 Ignition Transformer, complete 01
19 6162762 Control Box Socket 01
20 6162763 Control Box LMO 24 01
21 6163983 Bushing, 7-poles 01
23 6162764 Flame Control QRB4 01
24 6162701 Solenoid Valve 01
25 6163985 Motor 01
26 6163986 Coupling 01
27 6162757 Fixing Set 01
28 6163032 Burner Nozzle 2,25 GPH - 60° S 01
6162753 Relay 01
6162765 Misfire Relay
- 15 of 17 -
