WILMS KT 320 - Wiring Diagram

H 650 740 820
TH 740 825 905
Legend to
wiring diagram
P1 Hour meter
M2 Compressor with capacitor
KT 320 KT 420 KT 820
L 412 535 535
W 505 535 535
Position Description
J1 Connecting cable
B1 Air sensor
B2 Evaporator sensor
B3 Condenser sensor
B4 Waterstop
B5 Hygrostat (optional)
X3 Jack plug for hygrostat
M1 Fan motor
Y1 Solenoid valve
15
