Wilson Benesch A.C.T. One User Manual

WILSON BENESCH
A.C.T. ONE LOUDSPEAKER.
SPECIFICATION.
DESCRIPTION:
ADVANCED COMPOSITE TECHNOLOGY, LOUDSPEAKER.
TYPE:
FREE SPACE FLOOR STANDING.
RANGE:
FULL FREQUENCY;
30 Hz TO 20 KHz. +/- 2.5 dB 40 Hz TO 20kHZ.
IMP LOADING:
6 OHMS NOMINAL, 4.5 OHM MINIMUM. WITHIN 1-3 OHMS TOLERANCE 50 Hz TO
20KHz.
SENSITIVITY:
89dB / WATT, 2.83 v INPUT.
LOW FREQ LOADING:
BESSEL ALIGNMENT OF FOURTH ORDER REFLEX, DOUBLE CHAMBER
DIFFERENTIAL TUNING
CROSSOVER:
MINIMUM PHASE, PRIMARILY LOW ORDER 6dB / OCTAVE , SHORT SIGNAL PATH.
AIR CORE INDUCTORS, SELECTED POLYPROPYLENE CAPACITORS.
BASS DRIVER:
WILSON BENESCH DRIVE UNIT.
BASS-MID DRIVER:
WILSON BENESCH DRIVE UNIT.
TREBLE DRIVER:
WILSON BENESCH DRIVE UNIT.
INTERNAL WIRING:
MULTI STRAND SILVER PLATED STRANDED COPPER, TEFLON JACKET.
INPUT:
TRI AND BI WIREABLE.
POWER HANDLING:
200 w PEAK UNCLIPPED PROGRAMME.
MAXIMUM LEVEL:
112 dB AT 1 METRE.
INTERNAL VOLUME:
APPROX 39 LITRES.
SIZE:
HEIGHT: 1000 mm.
WIDTH: 230 mm.
DEPTH: 370 mm
WEIGHT: APPROX 48 Kg.
© Copyright Wilson Benesch Ltd All rights reserved 1999

Wilson Benesch A.C.T. One Specifications

General

Brand	Wilson Benesch
Model	A.C.T. One
Category	Speakers
Language	English
