1 Blue cover on top
2 Upper pump housing
3 Holder
4 Holder
5 Engine
6 Pump holder
7 Lower pump housing
8 O-ring 1
9 Bearing cover
10 Bearing
11 Rotor
12 Rotor cover
13 O-ring 2
14 Flange
15 Screw
16 O-ring 3
17 Outlet
18 O-ring 4
19 Flange 2
20 Blue cover side
