PART LIST
1 Fixing nut 8 Upper bracket
2 Indicator glass 9 Quartz glass part
3 Gasket 10 o-ring
4 Outlet 1 11 M5 screw
5 Outlet 2 12 UV lamp
6 Stainless steel shell 13 UVC device head
7 M5 nut 14 Base
TROUBLE SHOOTING
malfunction Cause remedy
The unit perfor-
mance is not
satisfactory
1. water extremely soiled
2. quartz glass tube soiled
3. UVC lamp capacity exhausted
1. remove algae and leaves from the pond,
perform a partial water change
2. clean the quartz glass
3. replace the lamp after approx.8000 operat-
ing hours
UVC lamp
does
not light up
1. plug not connected
2. UVC lamp defective
3.connection defective
4.UVC overheated
1. connect plug
2. replacing the UVC lamp
3. check electrical connection
4. UVC automatically switches on
when cooled down
