14
Typical operations
(continued)
Sanding aluminum on the disc unit with the table tilted and using the
miter gauge as a guide (see Figure 26).
NOTE: Always sand on the left (downward) side of the sanding
disc, as shown. Sanding on the right (upward) side of the sanding
disc could cause the workpiece to fly up which could be hazardous.
Sanding outside curves on the belt unit with the platen removed
(see Figure 27).
Polishing using the accessory felt belt in place of the sanding
belt (see Figure 28).
NOTE: Most polishing operations are performed with the platen
removed.
Sanding in tight areas with the sanding belt (see Figure 29).
Figure 26. Sanding aluminum
Figure 27. Sanding outside curves Figure 28. Polishing using a felt belt
Figure 29. Sanding in tight areas
