17
Item Part
No. Number Description
1 564003-1 Hex. Socket Head Screw (M10 x 40 MM)
2 564004-1 Flat Washer (12 MM)
3 564005-1 Spring
4 564006-1 Spacer
5 564007-1 Tracking Adjustment Screw
6 564008-1 Spring
7 564009-1 Support
8 564015-1 Spring Pin (M3 x 20 MM)
9 564016-1 Idler Shaft
10 564017-1 Idler Shaft
11 564018-1 Hex. Soc. Set Screw (M5 x 5 MM)
12 564019-1 Hex. Soc. Set Screw (M5 x 12 MM)
13 564025-1 Drive Pulley
14 564026-1 Retaining Plate
15 564027-1 Slot Hd. Mach. Screw (M4 x 12 MM)
16 564028-1 Lock Washer (4.1 MM)
17 564029-1 Ball Bearing
18 564033-1 Key
19 564034-1 Main Drive Shaft
20 564035-1 Ball Bearing
21 564036-1 Frame
22 564029-1 Ball Bearing
23 564037-1 Idler
24 564038-1 Flat Washer (6.4 MM)
25 564039-1 Upper Cover
26 564043-1 Hex. Socket Head Screw (M6 x 10MM)
27 564044-1 Hex. Socket Head Screw (M10 x 20MM)
28 564045-1 Lock Washer (10 MM)
29 564046-1 Flat Washer (10 MM)
30 564047-1 Platen
31 564048-1 Spacer
32 564029-1 Ball Bearing
33 564037-1 Idler
34 564049-1 Retaining Ring
35 564051-1 Hex. Socket Setscrew (M5 x 16 MM)
36 564052-1 Drive Wheel
37 564010-1 Sanding Belt - 50 Grit
564011-1 Sanding Belt - 80 Grit
564012-1 Sanding Belt - 120 Grit
564013-1 Sanding Belt - 220 Grit
564014-1 Sanding Belt - 320 Grit
564030-1 Abrasive Belt, Non-woven - Fine
564031-1 Abrasive Belt, Non-woven - Medium
564032-1 Abrasive Belt, Non-woven - Coarse
38 564054-1 Nut
39 564055-1 Washer
40 564058-1 Bolt
41 564057-1 Knob
42 564063-1 Washer
43 564059-1 Cover
44 564068-1 Lockwasher
45 564062-1 Table
46 564061-1 Knob
47 564064-1 Clamp Assembly
48 564065-1 Special Washer
49 564066-1 Bracket
50 564067-1 Flat Washer (8,4 MM)
52 564069-1 Screw (M8 x 15 MM)
70 564046-1 Flat Washer (10 MM)
71 564045-1 Lock Washer (10 MM)
72 564044-1 Hex. Socket Head Screw (M10 x 20MM)
103 564056-1 Rotation Label
