General Specifications
The Wilton Square Wheel Belt Grinder,
Models 4103, 4106 and 4126AC, are
designed for grinding, deburring,
chamfering, and internal/external grinding of
small and large parts. The Square Wheel
Belt Grinder can be used to polish or buff
finished parts and grind small internal radii
using available accessories. Accessory
changeover is quick and easy. Belt tension
and tracking are easily adjustable.
The Square Wheel Belt Grinder is available
in either single speed (Models 4103 and
4106) or variable speed model (Model
4126AC). The variable speed model is
controlled by an inverter that provides belt
speeds ranging from 0 to 6000 SFPM.
Specifications Model 4103 Model 4106 Model 4126AC
Belt Width & Length 2 x 72 Inches 2 x 72 Inches 2 x 72 inches
Belt Speed 4600 SFPM 4600 SFPM 0 - 6000 SFPM
Motor 1 HP, Single Phase, 2 HP, Three Phase, 1 HP, 1,750 rpm
1750 rpm 1750 rpm
Contact Wheel Diameters 1-1/2, 3, & 8 inches 1-1/2, 3, & 8 inches 1-1/2, 3, & 8 inches
Weight 115-125 pounds 120 pounds 120 pounds
