Parts Listing – Model 4400A Disc Sander Assembly
Ref # Part No. Description Qty.
1 5508427 Bracket 1
2 TS-1523011 SHSS, M6 x 6 2
3 5511725 4200 Arbor Pulley 1
4 TS-1504061 SHCS, M8 x 30 4
5 TS-2361081 Lock Washer, M8 4
6 5508443 Drive Shaft 1
7 5051451 Key, 5 x 5 x 35 1
8 4200A-042 Key, 5 x 5 x 55 1
9 BB-6204ZZ Ball Bearing, 6204ZZ 1
10 5051471 Retaining Ring, S20 1
11 VB-A59 V-Belt, A59 1
12 5511818 Pan Head Screw, M5 x 6 4
13 5508444 Belt Guard Assembly 1
14 BB-6205ZZ Ball Bearing, 6205ZZ 1
15 5508439 Locking Bushing 1
16 TS-1550061 Flat Washer, M8 1
17 TS-1490031 Hex Cap Screw, M8 x 20 1
18 4400A-018 Glue Bushing 1
19 4200A-105 Label, Direction 1
20 4400A-020 Label, Warning 1
21 4400A-021 Label, Warning 1
22 TS-1540071 Hex Nut, Full, M10 4
23 TS-2210801 Hex Cap Screw, M10 x 80 4
24 TS-1550071 Flat Washer, M10 8
25 5508447 Base 1
26 TS-1550071 Flat Washer, M10 2
27 TS-2361101 Lock Washer, M10 4
28 5508450 Hand Knob 2
29 5508451 Clamp with Pins 2
30 4200A-090 Roll Pin, M6 x 45 4
31 5508462 Stud 2
32 5508453 Disc Guard 1
33 TS-2361101 Lock Washer, M10 2
34 TS-2239551 SHCS, M10 x 55 2
35 5051741 Pointer 1
36 TS-1523021 SHFS, M6 x 8 1
37 TS-1523031 SHSS, M6 x 10 2
38 5051641 Disc, Aluminum 1
39 5051631 Garnet Disc 1
40 5508449 Table 1
41 5051681 Trunnion 2
42 TS-2361081 Lock Washer, M8 4
43 TS-1490041 Hex Cap Screw, M8 x 25 4
44 5051701 Tilting Table Scale 1
45 5511824 Drive Screw, M2 x 5 2
46 5052271 Deluxe Miter Gauge 1
