14
53 5042011 Key (Motor) 1
54 9077101 Variable Speed Belt 1
55 5041140 Vaiable Speed Pulley (Spindle) 1
55A 5513510 Hex Nut 1
55B 5513511 SHCS 1
56 9100421 Bearing 1
57 9058571 Spring Washer 1
58 5041761 Speed Change Nut 1
59 5041040 Speed Change Lever 1
60 9127951 Socket Set Screw 1
1/4-20 x 1/2
61 9057461 Washer 1/4 3
62 9052101 Hex Head Cap Screw 4
1/4-20 x 1
63 5041271 Right Mounting Plate 1
64 5518170 Self Tapping Screw 7
3/16-24 x 3/8
68A
TS-0208041 SHCS 5/16-18x3/4 2
68B 5513513 Spacer, Threaded 1
68C 5513514 Plate, Bracket 1
68D 5513515 Pickup, Magnetic 1
68E 5513516 Screw 2
68F 5513521 Plate 1
69 5041320 Cover, Pulley 1
69A 5513517 Bracket, Face Plate 1
70 5513518 Plate, Face 1
70A 5513519 LED Display 1Ph 1
5513736 LED Display 3 Ph
70B 5513520 Screw, Locking 1
72 9056771 Hex Jam Nut 3/8-16 1
75 5041000 Head Casting 1
76 5518172 Left Mounting Plate 1
77 9052831 Socket Set Screw 1
3/8-16 x 1
78
TS-0267101 Socket Set Screw 1
1/4-20 x 1-1/4
80 9052971 Socket Set Screw 1
5/16-18 x 5/16
81 5034111 Hand Wheel 1
82 5513737 Shaft speed change lever 1
86 9129051 Hex Nut 7/16-14 1
87 5041470 Collar 1
88 9128071 Hex Head Cap Screw 1
7/16-14 x 3-1/2
89 5032560 Motor Mounting Bracket 1
94 TS-0680032 Washer 5/16 4
96 5507505 Return Spring Bracket 1
97 5507507 Drift Pin 1
98 5507506 Switch Mounting Plate 1
99 5507527 Quill Assembly (Note 1) 1
100 5507812 Motor, 1 PH 115/220
1725 RPM 60 Hz 1
5514604 Motor, 1PH 115/220
1725 RPM 50 Hz 1
5507813 Motor, 3 PH 220/440
1725 RPM 50/60 Hz 1
1 5507580 Chuck (with Key) 1
2A 5507495 #2 MT x JT3 Arbor 1
3A 5507496 Spindle Assembly 1
4 5053070 Quill Band 1
5 9010541 O-Ring 1
6 9054511 Set Screw 2
5/16-18 x 3/8
7 5032611 Bearing Retainer 1
8 9100331 Bearing 2
9 5041010 Quill 1
10 9058561 Wavy Spring Washer 1
11 9074081 Truarc Retainer 1
13 9056981 Hex Jam Nut 3
1/4-20
16 5518170 Sloted self taping Screw 5
3/16-24 x 3/8
17 5518157 Power Cord (1-Phase) 1
17A 5517463 Power Cord (3-Phase) 1
18A 5507500 Switch (Single Phase) 1
5507497 Switch (3-Phase) 1
19A 5507501 Slotted Machine Screw 4
1/4-20 x 1
21 5518158 Wiring Harness (1-Phase) 1
5517457 Wiring Harness (3-Phase) 1
24A 5507502 Socket Head Cap Screw 3
25A 5507503 Return Spring Assemlby 1
26A 5507504 Nylon Nut 1
27 9135311 Lock Screw 1/4-20 x 1 2
28 5041050 Speed Change Housing 1
29 9127731 Socket Set Screw 1
5/16-18 x 5/16
30 5024541 Head Lock (Plain Side) 1
31 1000771 Lock Nut Assembly 1
32 5041071 Speed Change Shaft 1
33 9053661 Retainer 1
34 5041201 Bearing Spacer 1
35 9100321 Bearing 2
36 9070291 Knob 3
37 5053000 Spoke 3
38 5507827 Feed Shaft Assembly 1
39 5513378 Hi/Lo Speed Direction Plate 1
40 5053100 Rod, Graduated 1
41 9056381 Jam Nut 5/8-11 3
42 9128611 Hex Head Cap Screw 1
1/2-12 x 4
44
TS-0270031 set Screw 4
5/16-18 x 3/8
45 5032781 Motor Plate Bar 4
46 9057111 Whiz Flange Locknut 4
47 TS-0152051 Carriage Bolt 5/16-18 x 2 4
48 9056171 Carriage Bolt 4
5/16-18 x 1-1/2
49 9058051 Split Lock Washer 1/2 ID 2
50 9056841 Hex Nut 1/2-12 2
51 5041170 Variable Speed Pulley (Motor) 1
52 9054621 Socket Set Screw 1/4-20 x 1/2 2
Item Part
No. Number Description Qty
Item Part
No. Number Description Qty
Note 1: Quill assembly includes items 5, 7, 8, 9,10 and 11.
Parts List - Head
Models A5816, A5818, A5836 and A5838
