Wilton A3816 User Manual

18
Parts List - Base
(Floor Models A5816, A5818, A3816 & A3818)
Item Part
No. Number Description Qty
1 1000771 Locknut 1
2 5003751 Table Lock (Plain Side) 1
3 5507508 Table 1
4 5507509 Hex Head Cap Screw 1
5 TS-0061091 Cap Screw 1
7/16-14 x 3-1/2
6 5041470 Collar 1
7 9129051 Hex Nut 7/16-14 1
8 5507528 Base 1
9 5507510 Standard Column 1
5511850 Short Column 1
10 5507511 Flange (Base/Column) 1
11 5630771 HHCS 1/2-12 x 1-1/2 4
12 5507571 Cover Plate 1
13 5507570 Bushing 1
14 5507513 Worm, Table Raiser 1
15 5507514 Gear, Table Raiser 1
16 5507515 Shaft, Table Raiser 1
17 5507516 C-Ring, Table Raiser 2
18 TS-0050051 SHCS 1/4 x 1 4
19 5507518 Socket Head Set Screw 1
5/16-18 x 3/8
20 5507519 Crank, Table Raiser 1
21 5507520 Handle, Table Raiser 1
22 5507521 Rack 1
23 5507522 Rack Ring 1
25 5507816 Table Raiser Assembly 1
