c. Pin Depth Measurements.
Gauging sets for measuring terminations are avail-
able from WILTRON. Table 5 provides a listing that
correlates each SWR Autotester and bridge type
with its appropriate gauging set. Instructions for
gauging air line connectors are provided with gaug-
ing set.
8. MAINTENANCE
WILTRON recommends that no maintenance other
than cleaning be attempted by customer. The SWR
Autotester or bridge should be returned to WIL-
TRON for repair and/or service when needed.
Clean connector interfaces with clean cotton swab
dampened with alcohol.
CAUTION
Excessive pressure when cleaning can
damage the center conductor support
bead in the SWR Autotester or Bridge.
Ensure that the cotton swab is small
enough to fit into the connector with-
out applying pressure to the center
conductor. When cleaning, limit the
pressure so as to lightly contact the
connector. To obtain cotton swabs that
are smaller than the standard type
available in most retail outlets, try
contacting a medical-lab-type supply
center.
CAUTION
If installed, do not disturb the teflon
washer on the center conductor (refer to
paragraph 5c).
Model Connector Type
Gauging Set
Model
60A50, 58A50,
87A50, 87A50-1
63A50, 59A50,
97A50, 97A50-1
GPC–7 01-161
60N50, 62N75,
63N50, 97N50,
97N50-1
N Male
01-163
60NF50, 62NF75,
63NF50, 97NF50,
97NF50-1
N Female
97S50, 97S50-1 WSMA Male
01-162
97SF50, 97SF50-1 WSMA Female
Table 5. Available Gauging Sets
10 SWR OMM
