Step 1 - Remove and discard the temporary spoke.
Step 2 - Remove the box of spokes from inside the safe. Unpack each spoke from
packaging.
OPTIONAL STEP: Apply one drop of spoke handle thread lock on the threads before
screwing in the handles. (This will result in permanent installation.)
Step 3 -Screw handles into the spoke hub.
OPTIONAL
Images are for instruction only and may not look identical to the handle on your particular safe.
Step 1 - Locate the temporary spoke.
WARNING: Do not apply Spoke Handle
Thread Lock on temporary spoke.
Step 2 - Screw in the temporary spoke
at the bottom of the handle hub.
HANDLE INSTALLATION
INSTALLING THE TEMPORARY SPOKE
The temporary spoke provided is used to assist in opening the safe for the rst time only.
(SEE NEXT PAGE FOR INSTRUCTION.)
INSTALLING THE HANDLE SPOKES
