5586356230 Chariot iGloss
Burnishing Deck
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86354980 1 MOTOR, 36VDC 3 HP 2000RPM
2 86135970 1 KEY, 3/16 SQ X 5/8 LONG
3 86353470 1 BRACKET, MOTOR LIFT
4 86352910 1 SHROUD, OUTER
5 86353780 1 BRUSH, FLEXIBLE STRIP, 72" LONG
6 86352900 1 SHROUD, INNER
7 86353750 1 PLATE, SUPPORT, INNER SHROUD
8 86276920 4 SCREW 3/8-16x1
9 86352450 1 HUB, PAD DRIVER
10 86010710 1 WASHER .5 X 1.25 FLAT GR8 PLT
11 86277540 1 SCREW 7/16-20 X 1 HHCS PLTD
12 86006930 1 SCREW 5/16-18 X 1.00 BSHCS SS
13 86330990 1 WASHER, 5/16 INT STAR, SS
14 86228840 1 BEARING FLANGED.314IDX.502OD
15 86279030 1 WASHER, .53 ID X 1.5 OD TEFLON
16 86007910 2 SPRING EXT .31D X 2.0L X .03W
17 86353760 1 BRACKET, MOTOR LOCK
18 86279110 4 WASHER, 3/8 ID INT.LOCK
19 86271910 2 NUT, 5/16-18 FLEXLOCK
20 86010670 2 WASHER 5/16 FLAT SS
