5786356230 Chariot iGloss
Burnishing Deck Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86353790 2 BRACKET, LINKAGE ARM
2 86277030 8 SCR, 5/16-18X1.25 CARRIAGE SS
3 86228840 8 BEARING FLANGED.314IDX.502OD
4 86259410 8 WASHER THRUST.51 ID X1ODX.063
5 86279350 16 WASHER, WAVE 1/2ID X3/4D X.125
6 86259420 8 WASHER, THRUST .51ID X 1 ODBRO
7 86010670 14 WASHER 5/16 FLAT SS
8 86270830 12 NUT 5/16-18 HEX NYLOCK SS
9 86276070 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
10 86271840 2 SP NUT 5/16-18 HEX NYLOCK THIN SS
11 86353740 1 BRACKET, LIFT ASSY, TOP
12 86010770 2 WASHER 7/16ID X1DX.08 FLT SS
13 86353810 2 BOLT SHOULDER, 3/8 OD X 1/4 L SS
14 86010680 2 WASHER 3/8 ID X 3/4 OD NYLON
15 86353800 2 BRACKET, SPRING LIFT
