6186356230 Chariot iGloss
Pad Driver
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86352460 1 HUB, PAD DRIVER
2 86355650 1 GROMMET, .188ID x .438OD x .188T
3 86173140 3 SCR, KA40X16,PT OVAL,WN1412,PL
4 86355620 1 RETAINER, PAD CENTER LOCK
5 86173330 8 WASHER, M5, FLAT, ISO7093, SS
6 86327910 8 SCR, KA50X25, PT OHS, WN1412, PLTD
7 86355610 1 PAD DRIVER, FACE 20"
8 86172940 3 SCR,KA40X10,PT OVAL,WIN1412,PL
- 86358450 - ASM, PAD DRIVER iGLOSS 20 NOT SHOWN
