Windsor Chariot 2 iGloss 20 CBPS20 User Manual

7786356230 Chariot iGloss
Drive Mounting
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86326080 1 BRACKET, LINKAGE MOUNT, RIGHT
2 86319730 1 BRACKET, LINKAGE MOUNT, LEFT
3 86331630 1 BRACKET, ROLLER GUIDE
4 86010670 12 WASHER, 5/16 X 3/4 SS
5 86276690 8 SCR, 5/16-18 X 1.75 CARR SS
6 86276070 2 SCR, 5/16-18 X 3/4 CARRIAGE SS
7 86270830 12 NUT, 5/16-18 HEX NYLOCK SS
8 86274760 1 SCR, 1/4-20 X 1/2 HHCS
9 86363870 1 CLAMP, 5/8” OD CUSHIONED
10 86329340 1 PLATE, CHAIN GUARD
11 86278940 1 WASHER 1/4 ID X 1-1/4 OD PLT (1*)

Windsor Chariot 2 iGloss 20 CBPS20 Specifications

General

Brand	Windsor
Model	Chariot 2 iGloss 20 CBPS20
Category	Floor Machine
Language	English
