7986356230 Chariot iGloss
Console - Bag Enclosure
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES
1 86173140 2 SCR, KA40X16,PT OVAL,WN1412,PL
2 86161800 1 CATCH CONCEALED KEEPER
3 86353230 1 COVER, BAG ENCLOSURE
4 86353650 1 SHAFT, .25 X 7.3, SS
5 86275810 4 SCR, 10-32 X 1 PPHMS BLK
6 86010650 4 SP WASHER #10 X 9/16 OD
7 86005640 1 NUT 10-32 HEX NYLOCK
8 86353170 1 BRKT, HINGE
9 86228790 2 BEARING FLANGE .88ODX.75IDX.75
10 86327830 1 GASKET,.188X.31X41.0
11 86276330 2 SCR, 1/4-20 X 1.25 CARRIAGE BZ
12 86279520 4 WASHER, 1/4 ID FLAT BLK
13 86356130 2 BUMPER, 7/8OD X 13/32H, RUBBER
14 86006600 2 SCREW #10 X 3/4 PPHST TYPE B SS
15 86354640 1 WASHER, 1.5ID SINK, RUBBER
16 86284790 1 FILTER BAG (10 PACK)
17 86007040 1 SCREW 5/16-18X1 THUMB SS TYPE P
18 86356820 1 WASHER, .315ID X .89OD X .215, NYL
19 86327680 1 SWITCH, INTERLOCK
20 86354590 1 BRACKET, BAG MOUNT
21 86354630 1 GASKET, BAG MOUNT
22 86271840 1 SP NUT 5/16-18 HEX NYLOCK THIN SS
23 86353660 1 GASKET, BAG COVER, 43.6"
24A 86353640 4 CONSOLE, iGLOSS 20, TRIMMED ACTIVE DUST CONTROL
24B 86358550 1 CONSOLE, PASSIVE, TRIMMED PASSIVE DUST CONTROL
25 86008320 1 SPACER, .314 X .59 X .36 NYLON
26 86359260 1
WASHER, 1.5 ID X 1.7 PD X .19,
RUBBER
