HANDLE
ROMBUS 980124 11/19/04
5-2
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 RMH 1 RMBS HANDLE ASM CMPLT
2 01014 1 CABLE RESTRAINT NOT SHOWN
3 01004 2 HANDLE GRIPS
4 01008 2 CAP PLUG
5 01009 1 CAP SCREW
6 01007 1 UPPER CABLE HOLDER, LOCKED
7 01088 1 CAP SCREW
8 01011 1 LWR CABLE HLDR, GYRATORY
9 01012 1 GYRATORY CBL RTNR SPRING
10 01013 1 BALL BEARING
11 01021 2 NYLON, INSERT NUT
12 01018 2 HANDLE BLOCKS
13 01017 1 5MM PINS
14A 01097 1 RMBS12 HANDLE BAR (MCHN SD) RMBS12 ONLY
14B 01098 1 RMBS16 HANDLE BAR (MCHN SD) RMBS16 ONLY
15 01090 1 PIN, DOWEL M5
16 01019 2 M8 BOLT
17 01020 1 THUMB WHEELS & WASHER
18 01015 1 CARRY HANDLES
19 01083 1 RMBS12/16 DECAL
20A 01093 1 SHAFT, LOCKING 12” RMBS12 ONLY
20B 01094 1 SHAFT, LOCKING 16” RMBS16 ONLY
21 01092 1 SCR, M10 SOCKET
22 01091 1 PIN, DOWEL M6
23 01089 1 SPRING, 24MM
24A 01095 1 BUSHING, LOCKING 12” RMBS12 ONLY
24B 01096 1 BUSHING, LOCKING 16” RMBS16 ONLY
25 01103 1 UPPER HANDLE BAR
26 01105 2 HANDLE CONNECTING BAR
27 01104 1 LOWER HANDLE SECTION
28 01106 8 SCR, M4 COUNTERSUNK
29 01107 8 WASHER, M4 S/S NOT SHOWN
30 01109 1 ALLEN KEY NOT SHOWN
