BASE - MOTOR
ROMBUS 980124 11/19/04
5-4
REF PART NO. QTY DESCRIPTION
SERIAL NO.
FROM
NOTES:
1 01042 8 BUTTON SCREWS
2A 01026 1 RMBS12 MCHN COVER RMBS12 ONLY
2B 01037 1 RMBS16 MCHN COVER RMBS16 ONLY
3 01070 1 CABLE 10M
4 01069 1 MOTOR CABLE 1M
5 01076 1 CABLE GLAND
6 01068 1 SWITCH LOCKING NUT
7 01067 1 SWITCH
8 01054 3 SCREW
9 01063 1 END HOUSING
10 01071 2 SCREW
11 01062 1 THERMAL RESET SWITCH COVER
12 01061 1 THERMAL RESET SWITCH
13A 01030 2 RMBS12 DRAW BARS RMBS12 ONLY
13B 01041 2 RMBS16 DRAW BARS RMBS16 ONLY
14A 01024 1 RMBS12 MTR SUPPORT – SWITCH END RMBS12 ONLY
14B 01035 1 RMBS16 MTR SUPPORT – SWITCH END RMBS16 ONLY
15A 01027 1 RMBS12 MOTOR RMBS12 ONLY
15B 01038 1 RMBS16 MOTOR RMBS16 ONLY
16 01075 2 CAPACITOR SUPPORT
17 01079 2 CABLE TIES
18 01053 1 CAPACITOR, RUN
19 01044 1 BEARING (MOTOR)
20 01043 1 CIRCLIP, 14MM
21A 01025 1 RMBS12 MTR SUPPORT – FAN END RMBS12 ONLY
21B 01036 1 RMBS16 MTR SUPPORT – FAN END RMBS16 ONLY
22 01045 1 CAPACITOR, START
23 01064 1 END HOUSING, GEAR
24 01046 4 WASHERS
25 01078 2 NUT
26 01051 2 BEARING, AXLE
27 01072 2 CIRCLIP, 15MM
28 01077 2 BEARING
29 01047 1 GEAR
30 01049 1 GEAR
31 01052 2 BEARING
32 01073 2 CIRCLIP, 11MM
33 01074 2 CIRCLIP, 35MM
34A 01048 1 GEAR PIOR TO SN 16487
34B 01108 1 GEAR, 6F 16488 **SN 12125 – 12145
35 01050 1 GEAR
36 01055 2 CAP SCREW
37 01057 2 CAP SCREW
38 01099 1 END HOUSING GEAR COVER
