COMPONENTS
86221970 17” SCRUBBER 01/03/07
3-4
14
13
12
11
10
9
8
7
6
5
4
3
2
1
1. Control Panel
2. Control Handle
3. Recovery Tank
4. Recovery Tank Drain Hose
5. Recovery Tank Domel
6. Scrub Brush/Pad
7. Solution Tank
8. Solution Tank Cover
9. Solution Tank Drain Hose
10. Solution Strainer
11. Solution Tank Support Lanyard
12. Squeegee
13. Vacuum Motor
14. Solenoid Valve
