10
9. Attach the (4) upper support frame brackets (E) to the ceiling mounting bracket (J). Each support bracket will
use (4) #6 X 3/8 SM Screws (I).
10. Measure the distance that the bottom of the range hood will be from the top of your range (see page 5 for
reference). Attach the (4) lower support frame brackets (E) to the upper support frame brackets (E). Each
support bracket will use (4) #6 X 3/8 SM Screws (I).
11. Some models will come with one-piece seamless stainless-steel ducting versus the two-piece seamed
stainless-steel ducting as shown below:
To Next Page
