Quick installation guide
Aug. Winkhaus GmbH & Co. KG ∙ Berkeser Straße 6 ∙ 98617 Meiningen
T +49 369 3950 - 0 ∙ www.winkhaus.com ∙ Subject to technical changes
Figure 3.1-5: Keep magnetic clip
1. Insert spacer (plastic)
2. Screw fittings
3. Screw cover (optional)
4. End position
5. Adjustment of magnetic clip
Figure 3.1-6: Magnetic clip
1. Insert magnetic clip;
Position of handle height 261 mm
2. End position
3. Adjustment of magnetic clip
1 1
2
3
3
5
4
2
Magnetic clip
