3-15
SECTION 3 –
DRIVING YOUR MOTOR HOME
CIRCUIT BREAKERS AND
FUSES – CHASSIS/DASH
AUTOMOTIVE 12-VOLT
The 12-Volt Automotive Fuses and Circuit
Breakers are conveniently located beneath the
left end of the dash in front of the driver seat.
Remove cover to access.
The circuit breakers will pop outward if they
are tripped. Simply push in to reset. Always
replace plug-in blade fuses with ones of the same
size and amperage rating/color.
Further Information
Refer to the chassis manual provided in your
InfoCase for additional information about
chassis-supplied fuses and circuit breakers.
Automotive 12-Volt
Circuit Breakers and Fuses
(Located beneath left end of dash)
-Typical View
