7-5
SECTION 7 –
PLUMBING
FILTERED WATER FAUCET
–If Equipped
The Filtered Water Faucet is connected to a
flow-through, activated carbon filter cartridge
that removes chlorine and odors for taste-free
drinking water.
Replacing the Water Filter
Cartridge
Replace the filter cartridge when water flow
from the faucet is too slow for convenience.
• Twist the filter cartridge “counter-clockwise”
about one-quarter turn, then pull it down and
out of the filter socket.
NOTE: A spring-loaded valve inside the filter
socket will block water from flowing out
of the socket when the filter cartridge is
removed.
• Insert a new filter cartridge up into the filter
socket as far as possible and twist it
“clockwise” one-quarter turn until it stops.
Water Pump
(Located in compartment
behind rear passenger side tire)
* Model 37F shown
-Typical Installation
Filtered Water Faucet
-Typical View
Water Filter Assembly
(Located below galley sink)
-Typical View
