Winnebago Fuse 23F 2019 User Manual

1-5
SECTION 1 –
INTRODUCTION
SPECIFICATIONS AND CAPACITIES
23A 23T 23F
Standard
Ford® Transit
Diesel Chassis
Standard
Ford® Transit
Diesel Chassis
Standard
Ford® Transit
Diesel Chassis
Feature Number
159 159 159
Length
24' 24' 24'
Exterior Height
1
10' 1.5" 10' 1.5" 10' 1.5"
Exterior Width
2
7' 6.25" 7' 6.25" 7' 6.25"
Exterior Storage
3
23.2 cu. ft.
35.2 cu.ft.
3
37.9 cu.ft.
3
Awning Length
16' 10' 4" 16'
Interior Height
6' 8" 6' 8" 6' 8"
Interior Width
7' 3" 7' 3" 7' 3"
Freshwater Tank Capacity
4
27 gal. 33 gal. 33 gal.
Water Heater Capacity
6 gal. 6 gal. 6 gal.
Holding Tank Capacity - Black
4
43 gal. 40 gal. 40 gal.
Holding Tank Capacity - Gray
4
40 gal. 43 gal. 43 gal.
Propane Capacity
5
13 gal. 13 gal. 13 gal.
Wheelbase
156" 156" 156"
GVWR
10,360 lbs. 10,360 lbs. 10,360 lbs.
GAWR - Front
4,130 lbs. 4,130 lbs. 4,130 lbs.
GAWR - Rear
7,275 lbs. 7,275 lbs. 7,275 lbs.
GCWR
6
13,500 lbs. 13,500 lbs. 13,500 lbs.
Fuel Capacity 25 gal. 25 gal. 25 gal.
Notes:
4
Capacities are based on measurements prior to tank installation. Slight capacity variations can result upon installation.
5
Capacities shown are the tank manufacturer's listed water capacity (W.C.). Actual filled propane capacity is 80% of listing due to
overfilling prevention device on tank.
6
Actual towing capacity is dependent on your particular loading and towing circumstances which includes the GVWR, GAWR, and
GCWR as well as adequate trailer brakes. Refer to the chassis operator's manual of your motor home for further towing information.
Some chassis are equipped with Flex Fuel capable engines, however the gasoline generator installed in your
motorhome is not capable of running on E85 fuel. Refer to the generator operator's manual for more information on
proper fuel.
All information is based upon the most recent data available. Visit the Winnebago Industries, Inc. web page – www.winnebagoind.com
– for the most current product information.
1
The height of each model is measured to the top of the tallest standard feature and is based on the curb weight of a typically equipped
unit. The actual height of your vehicle may vary by several inches depending on chassis or equipment variations. Contact your dealer
for further information.
2
Floorplans feature a wide-body design - over 96". You should be aware that some states restrict access on some or all state roads to
96" in body width. You should confirm the road usage laws in the states of interest to you.
3
The load capacity of your motor home is designated by weight, not by volume, so you cannot necessarily use all available space when
loading your motor home.
