SECTION 7 –
PLUMBING
WATER SYSTEM DRAIN VALVE LOCATIONS
MODEL SYSTEM DRAIN VALVE LOCATIONS
Model 23A Waterlines • Two (2) valves accessed behind bottom drawer in
drivers side bed.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve
(small “button” in center of connector) to drain any
water left in the city waterline.
Water Tank • One (1) valve accessed through passenger side
compartment door.
Water Heater • Drain plug on outside of coach behind service door.
Use socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve accessed through passenger side
compartment door.
Winterization
Valve
(Antifreeze
Siphon)
• One (1) valve accessed through passenger side
compartment door.
Model 23F Waterlines • Three (3) valves under access panel beneath bed
storage.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve
(small “button” in center of connector) to drain any
water left in the city waterline.
Water Tank • One (1) valve under access panel beneath bed
storage.
Water Heater • One (1) valve under access panel beneath bed
storage.
Water Heater
Bypass Valve
• One (1) valve under bed board.
Winterization
Valve
(Antifreeze
Siphon)
• One (1) valve under access panel beneath bed
storage.
