SECTION 7 –
PLUMBING
7-14
Model 23T Waterlines • Two (2) valves under dinette seat.
• Two (2) valves under shower. Remove panel to
access.
Also, place the tip of your finger inside the city water
connection and gently press the backflow valve
(small “button” in center of connector) to drain any
water left in the city waterline.
Water Tank • One (1) valve beneath galley.
Water Heater • Drain plug on outside of coach behind service door.
Use socket to remove drain plug.
Water Heater
Bypass Valve
• One (1) valve under dinette seat.
Winterization
Valve
Antifreeze
Siphon
• One (1) valve beneath galley. Remove front and rear
panel to access.
To Next Page
