9-3
SECTION 9 –
FURNITURE AND SOFTGOODS
Once the table is reattached onto the wall
support, make sure the table leg is secured into
the floor support bracket and the leg brace is
locked.
DINETTE/BED CONVERSION
–If Equipped
(Typical View – Your motorhome may
differ in appearance)
Dinette to Bed
1. Lift forward facing dinette seat cushion.
2. Press the Table Leg Release Button and fold
table leg UP until it “clicks” into locked (90-
degree) position.
3. Remove dinette table from the wall support by
lowering leg end of table and pivoting the
table to release from the wall.
4. Lower dinette table to the floor. Then lower
dinette seat cushion.
5. Unfasten the two snaps located behind the
forward facing dinette backrest cushion.
