SECTION 9
CARE & MAINTENANCE
9-10
dition is apparent. Refer to your chassis operating
guide for further information.
AUTOMOTIVE 12-VOLT FUSES AND
CIRCUIT BREAKERS
The automotive fuses and breaker are conve-
niently located on the automotive fuse/breaker
panel in the driver side front cargo compartment
as shown below.
The circuit breakers will pop outward if they
are tripped. Simply push in to reset.
Always replace plug-in type fuses with those
of the same amperage size.
Automotive 12-Volt Breaker Panel
Automotive 12-Volt Fuse Panel
GOOD FUSE
BAD FUSE
