WinWing EFIS-32L - Panel Mount 1 (MP1) Mounting; MP1 Sold Separately

15
4.3 Panel Mount 1 (MP1) Mounting
*MP1 Sold Separately
MP1 Package List
Note: MP1 is sold separately. For dimentions, please refer to MP1 User Manual.
2#
x8
x16
3#
x8
4#
x8
5#
T1
T2
1#
1 2
3
In this section, the materials shown in the figure will be described respectively as
“MP1+NUMBER”(such as MP1 1#, MP1 2#, MP1 3#).
Mounting Method:
Install the screws as shown.
