■ Use the following cables(Options)
The Power cable (Option) is a combination of
the AC adapter and AC cable.
USB bus power cable(Option)
* additional cable option : Power Y cable (compatible with microlot power source)
■ USB Interface
Pin Signal Descriptions
1 +5V +5V
2 Data - Scanner transmit data line
3 Data + Scanner transmit data line
4 GND System Ground
1
2
3 4
