9
Deep Cleaning (continued)
Distributor head
• Unclip the distributor head by pressing
upwards from below
(8)
.
• Disassemble the distributor head, hoses and
mixing funnels. Soak components in hot
water with cleaning agent.
Cleaning the dispensing area
• Remove drip guide
(9)
by pulling it up and
out.
• Unclip cup catcher unit with one hand and
remove it with the other using the hole in the
guiding plate for cup catcher
(10a)
.
• Unclip and remove cup slide with shutter
(10b)
.
Cup platform and drip tray
• Pull up and take out drip tray
(11)
.
• Press release lever of cup platform with your
left hand and pull up the cup platform with
your right hand
(12)
.
• Clean the area around the cup station on
front side of door.
Waste bucket
• Remove, empty and clean waste bucket
(13)
.
Cleaning inside and outside
• Clean the sensor of the waste bucket with a
clean, damp cloth and wipe dry.
• Clean the door and housing inside and
outside, and finally the bottom with a clean,
damp cloth.
• Flush all parts, which have been soaking,
thoroughly with clean and warm water.
Check that no dirt or cleaning agent
remains on the parts.
• Dry all parts with a dry cloth.
(see overleaf)
8
11
8
a
b
13
12
10
