Witter ZX404 - Release Cycle Clamp Arms; How to release cycle clamp arms; Towbar Nose Weight Limit; Check towbar nose weight limit

2.
1.
Remove and discard the M16 bolts,
washers and nuts.
Note: Always use new M16 bolts,
washers and nuts.
page 3
Check towbar nose weight limit ( S - Vertical Static Mass ) -
Never exceed this limit, the sum of the carrier and bikes must be
less weight than
this limit.
? KG
Vehicle Handbook
page 14
M5 x 40
x 3
M16 x 60
x 2
To tilt the bike rack rst support with your hands while you push the release
handle with your foot.
To avoid injury or damage, this operation of tilting the bike rack should be carried
out with assistance.
To close the bike rack lift until the release handle and mechanism click and engage
securely in the transit position.
The Tilt mechanism indicator must show Green before you commence
your journey.
transit positionrelease position
CARE MUST BE TAKEN WHEN TILTING THE CARRIER - WATCH YOUR HEAD AND FINGERS!
How to release cycle clamp arms with ratchet levers:
First push the release lever outwards, then pull out the strap.
Red Tilt mechanism Green
indicator
