6.2.3 Checking and changing the car sliding
shoe
(1) Remove the M6 screws holding the slide shoe
and the oil cup fixing
(2) Remove the lubricator cup with the fixing part
(3) Lift the guide shoe up for examination
(4) Change if needed
6.2.4 Changing the battery
(1) SWITCH OFF the battery (2) and the power of
EBRA20 (3) before changing the battery
NOTE! There may be 230 V in wires against
the earth.
(2) Remove the fixing and change the battery (1)
Blatt/
sheet
D7AJMGB.016
Datum/
date
23.05.2002
Stand/
version
B-24.05.2005
Geprüft/
approved
WAT/MZE
THE LMC LIFTCOMPONENTS MANUFACTURING AND COMMERCE COMPANY
Änderungen vorbehalten! Subject to change without notice!
Braking System EBRA20
Operating instruction
