SPECIFICATIONS
24", 30" and 36" Cooktops
FLUSH INSTALLATION
E
A
RECESS
21
1
/8"
(537)
RECESS
1
9
/16" (40) min
W
CUT-OUT WIDTH
COUNTERTOP CUT-OUT
19
1
/2"
(495)
2
1
/2" (64)
2
1
/2" (64)
10" (254)
4
1
/2" (114)
3
1
/2" (89)
FRONT VIEW
SIDE
VIEW
NO
TE: Shaded area above countertop indicates minimum clearance to combustible surfaces,
combus
tible materials cannot be located within this area.
El
ectrical supply location only applies to installations with built-in oven.
Outsid
e corner radius
7
/16" (11).
30"
(762)
13"
(330)
18"
(457)
2"
(51)
5
/16"
(
8
)
7
/8"
(22) MAX
COUNTERTOP
PROFILE
36" (914) min
FLOOR TO
COUNTERTOP
CUT-OUT WIDTH
INDUCTION / ELECTRIC COOKTOP W A
24" Induction 22
1
/8" (562) 23
3
/4" (603)
30" Induction / Electric 29" (737) 30
1
/8" (765)
36" Induction / Electric 35" (889) 36
1
/8" (918)
