HOT Surface Display - CE152TF/S
LED is time activated between 7 seconds and 370 seconds depending on what power level is selected. •
LED turns off after allotted time based on what power level is selected. •
LED will stay on a maximum of 60 minutes after all element assemblies are off.•
HOT Surface Display - CI152TF/S and TM15TF/S
LED is on when the unit glass temperature at any coil assembly (NTC reading) is greater than 149° F.•
LED turns off when the glass temperature is below 122° F.•
Independent of any control zone activation or the unit being in lock or showroom mode.•
HOT Surface Display - SM15TF/S and FM15TF/S
LED is on when the RTD, Steamer Fill Sensor is greater than 140° F.•
LED turns off when RTD, Steamer Fill Sensor is below 122° F.•
Independent of any control zone activation or the unit being in lock or showroom mode.•
HOT Surface Display - GM15TF/S
LED is on after the GM15TF/S has been on for more than five minutes.•
LED turns off when the GM15TF/S has been OFF for more than 30 minutes.•
Name Duration Type Occurrence
Valid Selection 280 ms Beep Touch on valid pad
Invalid Selection 750 ms Beep Touch on invalid pad
Acceptance 280 ms Beep Twice with 250 ms delay on the successful receipt of a command
Timer Complete 750 ms Beep
Four times with 200 ms delay on the expiration of a timer
Then every 8500 ms until acknowledge
Failure 750 ms Beep Four times with 200 ms delay on priority 1 errors
One Minute
Remaining
750 ms Beep When there is one minute remaining on a timer or timed cook cycle.
Frequency Duration and Selection Chart - All Models
NOTE: ms = milliseconds
